Tamiya 25T RS-540 Brushed Motor – Torque-Optimized Performance Model (Part #54358)

Description

TAMIYA 25T RS-540 Torque Tuned Brushed Motor – 54358

Tamiya has developed this Torque-Tuned motor, which offers performance that is between that of a standard Type 27T 540 size silver can motor and #53068 Sport-Tuned Motor. Compared to a standard Type 540 motor, it offers a higher top speed and improved acceleration when used with RC car models with standard gear ratios.

Get started with tuning by fitting this Type 540 motor! It will provide excellent acceleration and speed, and can be used on models from on-road to off, even on big tire vehicles!

Specs:

• Input voltage: 6.6-7.2V
• Torque at recommended load: 16,000rpm (7.2V)
• Maximum torque: 30mN
• Current consumption at recommended load: 10A (7.2V)

In a TT-01 or TT-02 you can expect average top speed for a given motor, as below:

• Standard 540-Turns: 27T *Top speed: 24.3Km/h
• Torque-Tuned Motor: Turns: 25T *Top Speed: 26km/h
• Sport-Tuned Motor: Turns: 23T *Top Speed: 29.1km/h
• *Measured using TT-01 chassis with kit-standard gear ratio.
