Description
E-FLITE DS60 0.94kg/cm 6g Super Sub-Micro Servo – EFLRDS60
Features
- Digital amplifier for superior accuracy, response and holding torque
- High speed .09 sec @ 60° @ 4.8V for quick control response
- High torque, 13.1 oz-in (0.94 kg-cm) @ 4.8V
- Precise centering – less than 1°
- Lightweight, just 6.0 grams
- Universal connector compatible with major brand receivers
- Includes complete mounting hardware
- Includes multiple servo arms including an extra-long 3D servo arm for extreme throws
Specs
- Type – Digital
- Application – Sub-micro and Micro-sized airplanes and helis
- Torque – 13.1 oz-in (0.94kg-cm) @4.8V; 16.1 oz-in (1.15kg-cm) @ 6.0V
- Speed – 0.09 sec/60° @ 4.8V; 0.08 sec/60° @ 6.0V
- Length – 0.92 in (23.5mm)
- Width – 0.40 in (10.0mm)
- Height – 0.96 in (24.0mm)
- Weight – 0.21 oz (6.0g)
- Motor Type – Coreless
- Connector Type – Universal
- Gear Type – Nylon
- Current Draw Idle – 25mA @ 4.8V
- Current Draw Stall – 560mA @ 4.8V
- Voltage – 4.8V-6.0V DC
- Deadband – <1μs
